ECP5-45F-8BG381C Datasheet, Pinout, Equivalents, and Specs

The ECP5-45F-8BG381C (ordering code LFE5U-45F-8BG381C) is an ultra-low-power FPGA from Lattice Semiconductor's ECP5 family, fabricated on a 40nm process. With 44,000 logic elements, 1,990 Kb of embedded block RAM (sysMEM EBR), 72 sysDSP slices delivering up to 144 multipliers (18x18), 4 PLLs, and embedded SERDES operating up to 3.2 Gbps, it targets cost- and power-sensitive applications requiring moderate logic density with high-speed serial connectivity. The device ships in a 381-ball caBGA package (17 x 17 mm) at commercial temperature grade (0 °C to 85 °C) with a -8 speed grade.

What Is the ECP5-45F-8BG381C?

The ECP5-45F-8BG381C belongs to the Lattice ECP5 family — a low-power, mid-range FPGA line built on 40nm technology, designed to bridge the gap between low-cost CPLDs and high-end FPGAs. The "ECP5" designation stands for "Efficient Connectivity Platform, 5th generation," and the "-45F" indicates the 45K LUT density variant. Internally, the device organizes 44,000 logic elements across 1,100 Logic Array Blocks (LABs), each containing programmable function units (PFUs) with 4-input look-up tables and associated flip-flops for combinational and sequential logic implementation.

On-chip memory is provided through 108 sysMEM Embedded Block RAM (EBR) blocks, each offering 18 Kb of true dual-port SRAM, totaling approximately 1,944 Kb (1.9 Mb) of on-chip storage configurable as single-port RAM, dual-port RAM, pseudo dual-port RAM, FIFO, or ROM. Distributed RAM using PFU slices adds further flexibility for shallow, high-bandwidth storage. The sysDSP architecture provides 72 DSP slices, each capable of implementing half a 36x36, two 18x18, or four 9x9 multiply-accumulate operations, supporting efficient FIR filters, FFTs, and signal-processing pipelines. Clock management relies on 4 PLLs and 4 DLLs for frequency synthesis, multiplication, division, and fine-grained phase adjustment.

Pinout Configuration and Packaging

The ECP5-45F-8BG381C is housed in a 381-ball caBGA (chip-array Ball Grid Array) package with a 17 x 17 mm body and 0.8 mm ball pitch. Of the 381 balls, 203 are available as general-purpose I/O pins organized into 8 I/O banks. Each bank supports independent VCCIO supply voltages, allowing mixed-voltage interfacing (1.2 V, 1.5 V, 1.8 V, 2.5 V, and 3.3 V) within a single device. The I/O structure supports both single-ended standards (LVCMOS, LVTTL) and differential standards (LVDS, BLVDS, MLVDS, LVPECL, sub-LVDS) for high-speed parallel interfaces.

Critical power pins include VCC (1.1 V core supply, range 1.045 V to 1.155 V), VCCIO (per-bank, selectable), and VCCAUX (3.3 V auxiliary). The device features dual-function configuration pins supporting Master SPI, Slave SPI, JTAG, and SSPI boot modes. The embedded SERDES block includes dedicated transmit and receive differential pairs for up to 3.2 Gbps serial connectivity. For PCB design, Lattice recommends a minimum 6-layer stackup with dedicated power and ground planes, 100 nF decoupling capacitors per VCC ball, and controlled-impedance routing for SERDES and LVDS pairs (100 ohm differential).

Specifications Parameter Table

Typical Applications and Circuit Considerations

The ECP5-45F-8BG381C targets designs requiring moderate FPGA density combined with low power consumption and integrated high-speed serial connectivity. The 40nm process delivers significantly lower static power than competing 65nm or 60nm alternatives at similar gate counts. Lattice positions the ECP5 family for connectivity bridging and processing acceleration in the following domains:

• Wireless Small Cell Infrastructure: CPRI front-haul bridging between baseband units and remote radio heads leverages the 3.2 Gbps SERDES, while DSP slices handle digital pre-distortion and crest-factor reduction for 4G/LTE deployments.
• Industrial Video and Display: HDMI/MIPI-to-parallel video bridging, frame buffering with sysMEM EBR blocks, and real-time color-space or resolution conversion for industrial HMIs, camera gateways, and multi-display controllers.
• Edge AI Inference Acceleration: The open-source toolchain (Yosys + nextpnr + Project Trellis) enables custom CNN accelerator overlays, with the 72 DSP slices implementing 8-bit or 16-bit MAC arrays for lightweight neural-network inference at the edge.
• Embedded Protocol Bridging: Gigabit Ethernet to PCIe, USB 3.0 PIPE interface implementation, and multi-protocol industrial gateways connecting EtherCAT, PROFINET, and Modbus TCP through the flexible I/O banks and SERDES channels.

From a circuit-design standpoint, Lattice recommends separate 1.1 V and 3.3 V power domains with ferrite-bead isolation between core VCC and VCCAUX. Each VCC ball requires a 100 nF decoupling capacitor placed directly beneath the BGA on inner PCB layers, with 10 uF bulk capacitors per power rail. SERDES differential pairs demand 100 ohm differential impedance with length-matched routing and AC-coupling capacitors at transmitter outputs. The SPI flash for configuration should be connected via dedicated MCLK, MSO, MSI, and MCS pins, supporting dual-boot capability for in-field firmware updates.

Video: Getting Started with Lattice ECP5 FPGA

Equivalents, Cross-Reference, and Lifecycle

The ECP5-45F-8BG381C carries an Active lifecycle status as of 2026, with no Product Discontinuation Notice (PDN) issued. Lattice Semiconductor continues to manufacture the ECP5 family through its 40nm foundry agreements. The device has strong support from the open-source FPGA community via Project Trellis, Yosys, and nextpnr, ensuring long-term software ecosystem viability.

Within the ECP5 family, the closest pin-compatible variants in the same BG381 package are:

• LFE5U-25F-8BG381C (ECP5-25F-8BG381C) — lower-density variant with 24,000 LEs, 56 EBR blocks, and 28 DSP slices. Pin-compatible drop-in for cost-optimized designs requiring less logic.
• LFE5U-85F-8BG381C (ECP5-85F-8BG381C) — higher-density variant with 84,000 LEs, 208 EBR blocks, and 156 DSP slices. Pin-compatible upgrade path for designs needing more resources.
• LFE5U-45F-8BG381I — industrial-temperature variant (-40 °C to 100 °C), functionally identical, same pinout.

Cross-family migration paths:

• Lattice ECP5-5G (LFE5UM5G-45F-8BG381C): Same die architecture with upgraded SERDES supporting up to 5.0 Gbps. Ideal for designs requiring higher-speed serial links.
• Lattice CrossLink-NX: Next-generation 28nm FD-SOI FPGA family offering improved power efficiency and hardened MIPI D-PHY interfaces for camera and display bridging applications.
• Intel Cyclone V (5CGXFC7C7F23C8N): Comparable 28nm FPGA with higher logic density (149,500 LEs) and hard memory controllers, offering an alternative for designs requiring more resources at higher power budgets.

For engineers evaluating alternative FPGAs, see also our technical guides on the ECP5-25F-8BG381C Lattice ECP5, the Intel 5CGXFC7C7F23C8N Cyclone V GX, and the EP4CGX150DF27C7N Cyclone IV GX.
