ADXL357BEZ Package and Pinout Reference
The ADXL357BEZ is a low noise, low drift, low power, 3-axis MEMS accelerometer. It is designed for high-performance applications such as inertial measurement units (IMUs), platform stabilization, and structural health monitoring. This article provides a comprehensive overview of its specifications, pinout, and key features.
Table of Contents
1. Overview and Core Features
The ADXL357BEZ offers a selectable measurement range of ±10 g, ±20 g, or ±40 g, and provides a digital output with 20-bit resolution. It features a hermetic package for excellent long-term stability and is equipped with a temperature sensor. The device communicates via a standard SPI or I2C digital interface.
2. Specifications and Parameter Table
| Parameter | Value |
|---|---|
| Axes | 3 (X, Y, Z) |
| Range | ±10 g, ±20 g, ±40 g |
| Noise Density | 80 µg/√Hz |
| Resolution | 20-bit |
| Interface | SPI / I2C |
| Supply Voltage | 2.25V to 3.6V |
| Operating Temperature | -40°C to +125°C |
Looking for ADXL357BEZ Inventory?
Check our real-time stock levels, pricing, and volume discounts for global distribution.
Check ADXL357BEZ Stock3. Architecture and Block Diagram
The ADXL357BEZ integrates a 3-axis MEMS sensor with a mixed-signal conditioning ASIC. The ASIC includes a low-noise amplifier, a 20-bit ADC, and a digital signal processor. The device provides factory-calibrated sensitivity and offset.
4. Video: Feature Breakdown
5. Equivalents, Cross-Reference, and Lifecycle
The ADXL357BEZ is an active and widely available component. For cross-reference, engineers can consider other high-performance accelerometers from the same family or competing devices with similar noise and stability specifications, though pin-to-pin compatibility is not guaranteed.
6. Frequently Asked Questions (FAQ)
What is the primary application for the ADXL357BEZ?
Its primary applications are in high-precision, motion-sensing scenarios like IMUs, tilt sensing, and structural health monitoring where low noise and long-term stability are critical.
What is the difference between the ADXL357 and the ADXL355?
The ADXL357 has a digital output, whereas the ADXL355 provides an analog output, requiring an external ADC.
