ADL5385ACPZ Package and Pinout Reference
The ADL5385ACPZ is a broadband quadrature modulator from Analog Devices, designed for high-performance RF applications. This document provides a detailed look at its specifications, pinout, and core features.
Table of Contents
1. Overview and Core Features
The ADL5385ACPZ is ideal for use in cellular infrastructure, satellite communications, and instrumentation, offering excellent modulation accuracy and low output noise.
2. Specifications and Parameter Table
| Parameter | Value |
|---|---|
| Frequency Range | 30 MHz to 2200 MHz |
| Supply Voltage | 4.75V to 5.5V |
| Package | 24-LFCSP |
Looking for ADL5385ACPZ Inventory?
Check our real-time stock levels, pricing, and volume discounts for global distribution.
Check ADL5385ACPZ Stock3. Architecture and Block Diagram
The device uses a Gilbert cell mixer core and includes on-chip quadrature generation. It is fabricated using a high-frequency bipolar process.
4. Video: Feature Breakdown
5. Equivalents, Cross-Reference, and Lifecycle
For alternatives and lifecycle status, please refer to the official Analog Devices documentation or contact our support team for a detailed cross-reference analysis.
6. Frequently Asked Questions (FAQ)
What is the frequency range of ADL5385ACPZ?
The frequency range is 30 MHz to 2200 MHz.
What is the supply voltage?
The supply voltage is 4.75V to 5.5V.
