The 10M04SCE144C8G is a non-volatile, single-chip FPGA from Intel's (formerly Altera) MAX 10 family, fabricated on TSMC's 55 nm flash process. It integrates 4,000 logic elements, 189 Kbit of M9K embedded SRAM, 16 hardware 18×18-bit multipliers, dual on-die configuration flash images, 1,376 Kbit of user flash memory, and 2 PLLs — all within a compact 144-pin EQFP package. Operating from a single 3.3 V supply with instant-on boot (under 10 ms), the 10M04SCE144C8G eliminates external configuration memory, reducing BOM cost and board area for industrial control, communications, and IoT edge applications.

Overview and Part Number Decoding

The 10M04SCE144C8G belongs to the Intel MAX 10 product line — the industry's first single-chip, non-volatile FPGA family. Unlike SRAM-based FPGAs such as Xilinx Spartan-7 or Intel Cyclone V that require external SPI flash for configuration bitstream storage, MAX 10 devices store up to two complete configuration images in on-die flash memory. This architecture enables instant-on operation within milliseconds of power-up and supports fail-safe remote field updates via the Remote System Upgrade (RSU) IP core — without any external EPCQ or SPI NOR flash on the BOM.

The part number encodes the following attributes:

• 10M04 — MAX 10 family, 4,000 logic elements
• SC — Single-supply, Compact variant (internal 1.2 V regulator, no integrated ADC)
• E144 — 144-pin Enhanced Quad Flat Package (EQFP) with exposed thermal pad
• C8 — Commercial temperature range (0 °C to +85 °C), speed grade 8
• G — Green / RoHS / Pb-free compliant

The “SC” designation distinguishes this variant from the “SA” (single-supply, analog) variants that include a 12-bit, 1 MSPS SAR ADC. In the SC variant, the analog input pins become general-purpose digital I/O or LVDS channels instead. The device is fully supported by Intel Quartus Prime Lite Edition, which is free to download and requires no license file. For current stock and pricing, check 10M04SCE144C8G availability on WWDParts.

Specifications and Parameter Table

Parameter	Value
Manufacturer	Intel (Altera)
Product Family	MAX 10
Part Number	10M04SCE144C8G
Logic Elements (LEs)	4,000
Logic Array Blocks (LABs)	250 (16 LEs per LAB)
M9K Embedded Memory Blocks	21
Total Embedded SRAM	189 Kbit
18×18 Embedded Multipliers	16
Phase-Locked Loops (PLLs)	2 (4 output counters each)
User Flash Memory (UFM)	1,376 Kbit
Configuration Flash Memory	Dual-image internal flash (instant-on, <10 ms boot)
User I/O Pins (E144 package)	101
I/O Banks	8
Maximum LVDS Differential Pairs	15
I/O Standards Supported	3.3 V / 2.5 V / 1.8 V / 1.5 V LVTTL/LVCMOS, LVDS, SSTL, HSTL
Maximum Fabric Frequency	402 MHz (register-to-register, speed grade 8)
M9K Maximum Speed	284 MHz
Core Voltage (VCC)	1.2 V (internally regulated from 3.3 V)
External Supply (VCCA / VCCIO)	3.3 V single rail (2.85–3.15 V)
Process Technology	55 nm (TSMC)
Package	144-EQFP (20 × 20 mm body, 0.5 mm pitch, exposed pad)
Operating Temperature	0 °C to +85 °C (Commercial)
Speed Grade	8
Integrated ADC	No (SC Compact variant; use 10M04SAE144C8G for ADC)
RoHS Compliant	Yes (Pb-free)
Lifecycle Status	Active (2026)

Architecture and Block Diagram

The MAX 10 FPGA architecture is organized around a fabric of configurable logic, embedded memory, and DSP resources interconnected by a hierarchical routing network with 20 global clock networks. The 10M04SCE144C8G integrates five core building blocks:

• 4,000 Logic Elements (LEs): Each LE contains a 4-input look-up table (LUT), a programmable register with synchronous load and asynchronous clear, carry chain logic, and register feedback. LEs are grouped into 250 Logic Array Blocks (LABs) of 16 LEs each, with dedicated local interconnect enabling fast intra-LAB routing at minimal skew.
• 21 M9K Memory Blocks (189 Kbit): Each 9,216-bit block (including parity) is configurable as single-port RAM, simple dual-port RAM, true dual-port RAM, ROM, or FIFO buffer. Supports data widths from ×1 to ×36 with byte-enable control, operating at up to 284 MHz.
• 16 Embedded 18×18-bit Multipliers: Dedicated DSP blocks for arithmetic operations. Each block operates as one 18×18-bit multiplier or splits into two independent 9×9-bit multipliers — suitable for FIR filters, PID control loops, motor drive algorithms, and fixed-point arithmetic pipelines.
• 2 PLLs: On-chip phase-locked loops provide clock synthesis, multiplication (up to ×512), division, and dynamic phase shifting. Input frequency range spans 5 MHz to 472.5 MHz with up to 4 independent output clocks per PLL, each with lock detect and dynamic reconfiguration.
• Dual Configuration Flash + 1,376 Kbit UFM: Two on-die configuration images enable fail-safe remote updates via the RSU IP core. The User Flash Memory stores calibration constants, serial numbers, or firmware data non-volatilely, accessible at runtime through the UFM IP core or Avalon-MM interface.

Figure 1: Intel MAX 10 FPGA family architecture — configurable logic fabric, embedded memory columns, PLLs, DSP blocks, user flash, and I/O ring. The 10M04SCE144C8G implements this architecture with 4K LEs and 21 M9K blocks.

Pinout, Package, and PCB Layout

The 10M04SCE144C8G is housed in a 144-pin EQFP (Enhanced Quad Flat Package) with a body size of 20 mm × 20 mm, 0.5 mm lead pitch, and a bottom-side exposed thermal pad. The package provides 101 user I/O pins organized across 8 I/O banks, each with an independent VCCIO supply rail for mixed-voltage interfacing.

Key pinout and layout considerations:

• VCCIO Banks: Each I/O bank supports independent VCCIO. For the “SC” single-supply variant, all VCCIO pins are typically tied to 3.3 V. Mixed-voltage designs can set individual banks to 2.5 V, 1.8 V, or 1.5 V for direct interfacing to external ICs.
• JTAG Pins (TCK, TDI, TDO, TMS): Dedicated configuration and boundary-scan pins. Apply 10 kΩ pull-up resistors on TDI and TMS, even when JTAG is unused in production — these pins must not float.
• MSEL[0]: Configuration mode select. Tie to GND for internal configuration mode (standard for MAX 10 instant-on operation).
• Power / Ground: All VCC and GND pins must be connected. Place 100 nF MLCC decoupling capacitors on every power pin, plus a 10 µF bulk capacitor per supply rail near the device.
• Exposed Thermal Pad: The center pad on the package bottom must be soldered to a continuous ground plane for thermal dissipation. Use at least 9 thermal vias (0.3 mm drill) under the pad connecting to inner ground planes.
• LVDS Pairs: Up to 15 true differential LVDS pairs are available. Route with 100 Ω differential impedance, matched-length, on inner PCB layers.

Figure 2: 10M04SCE144C8G in 144-EQFP package — 20 × 20 mm body, 0.5 mm pitch leads, exposed thermal pad on the underside for improved heat dissipation.

Application Circuits and Design Guidelines

The 10M04SCE144C8G targets systems requiring instant-on, non-volatile programmable logic with minimal external component count. Typical application domains include:

• Industrial Automation: Motor drive encoder interfaces, PLC I/O expansion modules, sensor aggregation hubs, and protocol bridging (SPI ↔ UART, I2C ↔ parallel bus). The instant-on capability ensures deterministic control outputs within milliseconds of power-up.
• Communications Equipment: Small-cell baseband glue logic, Ethernet MAC-to-PHY bridging, CPRI/OBSAI framing, and multi-protocol serial conversion. The 16 embedded multipliers handle DSP pre-processing in the datapath.
• Board Management Controllers: Voltage rail power sequencing, system health monitoring (temperature, current), fan speed control, and watchdog supervision. The dual-image flash enables safe firmware updates in the field.
• IoT and Edge Computing: Smart sensor hubs, LED matrix display controllers, HMI panel interfaces, and compact data loggers. The 1,376 Kbit UFM provides non-volatile storage for calibration data and event logs without external EEPROM.

Power Supply Design: The “SC” single-supply variant requires only a single 3.3 V rail (2.85–3.15 V). The internal 1.2 V core regulator draws approximately 50–150 mA depending on logic utilization and clock frequency. Texas Instruments reference design TIDA-00607 demonstrates a complete MAX 10 power solution using the TPS65218 PMIC from a single 5 V or Li-Ion input.

PCB Layout Best Practices:

• Use a 4-layer minimum stackup (signal–ground–power–signal) with dedicated power and ground planes
• Route clock signals on inner layers with 50 Ω controlled impedance; use 100 Ω differential for LVDS pairs
• Keep PLL input clock trace lengths under 50 mm with length-matched output clock routing
• Provide a 10-pin JTAG header (2×5, 2.54 mm pitch) with trace lengths under 150 mm
• Tie MSEL[0] to GND for internal configuration; the device boots in under 10 ms from power-up

Figure 3: MAX 10 FPGA development board — a typical application platform showing power supply section, JTAG programming, user I/O headers, and peripheral expansion for prototyping with the 10M04SCE144C8G.

Equivalents, Cross-Reference, and Lifecycle

The 10M04SCE144C8G carries an Active lifecycle status as of 2026 and is broadly stocked by major distributors including Digi-Key, Mouser, Arrow, and LCSC.

Pin-compatible alternatives within the MAX 10 family:

• 10M04SAE144C8G — The “SA” analog variant in the same 144-EQFP package. Pin-compatible drop-in that adds a 12-bit, 1 MSPS SAR ADC with up to 9 analog channels. No PCB redesign required.
• 10M08SCE144C8G — Same package, doubled to 8,000 LEs with 378 Kbit embedded RAM (36 M9K blocks). Pin-compatible logic capacity upgrade.
• 10M04SCE144I7G — Industrial temperature variant (−40 °C to +100 °C), speed grade 7. Same pinout for harsh-environment deployments.

Cross-vendor alternatives:

• Lattice MachXO3LF-4300 (LCMXO3LF-4300C-5BG256C): Comparable logic density (~4,300 LUTs) with integrated flash. Requires Lattice Diamond; pinout is not compatible.
• Microchip PolarFire MPF100T: Higher-density, low-power flash FPGA for designs outgrowing MAX 10 capacity.

Unit pricing for the 10M04SCE144C8G typically falls in the $8–$15 USD range depending on quantity. To check real-time stock, pricing, or request a quote, upload your BOM to WWDParts for fast processing.
