BAV99-Q Package and Pinout Reference
The BAV99-Q is a high-speed switching diode array, commonly used in automotive and other high-reliability applications. It consists of two series-connected diodes in a small surface-mount package. This article provides a technical overview of its specifications, configuration, and applications.
Table of Contents
1. Overview and Core Features
The BAV99-Q is AEC-Q101 qualified for automotive applications, ensuring high reliability and performance. Its key features include a very fast switching speed and low capacitance, making it ideal for high-frequency signal processing and protection circuits. The SOT-23 package allows for dense circuit board designs.
2. Specifications and Parameter Table
| Parameter | Value |
|---|---|
| Configuration | Dual Series |
| Repetitive Peak Reverse Voltage | 70V |
| Average Forward Current | 215mA |
| Reverse Recovery Time | 3 µs |
| Package | SOT-23 |
| Qualification | AEC-Q101 |
Looking for BAV99-Q Inventory?
Check our real-time stock levels, pricing, and volume discounts for global distribution.
Check BAV99-Q Stock3. Architecture and Block Diagram
The BAV99-Q contains two high-speed silicon epitaxial diodes connected in series within a single package. This configuration is useful for various circuit designs, including voltage multiplication, signal rectification, and protection. The monolithic construction ensures close matching of the diode characteristics.
4. Video: Feature Breakdown
5. Equivalents, Cross-Reference, and Lifecycle
The BAV99-Q is a very common and actively manufactured component, widely available from multiple sources. It is considered a standard part in the electronics industry. Cross-referencing to other dual-diode arrays in a SOT-23 package is straightforward, but AEC-Q101 qualification should be verified if required.
6. Frequently Asked Questions (FAQ)
What does the '-Q' suffix mean in BAV99-Q?
The '-Q' suffix indicates that the component is AEC-Q101 qualified, meaning it is approved for use in automotive applications due to its high reliability and robustness.
Can I use a standard BAV99 instead of a BAV99-Q?
For non-automotive applications, a standard BAV99 can often be used. However, for any automotive or high-reliability use case, the BAV99-Q is required to meet the necessary quality standards.
